Load distribution of first flank
| Symbol | - |
|---|---|
| Unit | -- |
| Attribute-ID | result_load_distribution_first_flank |
| Numeric ID | 10431 |
| Value Type | PMTechArray |
Specification of whether the static load distribution should be calculated and output.
The static load distribution is formed from two meshed rolling contact partners at a tooth load of F= const. and a speed of rotation n→0 (very slow rotation).
| A | Load distribution |
| I | Mesh position I |
| II | Mesh position II |
| I, II, ... | All mesh positions |
| gα | Path of contact |
| b | Contact width |
The transmission deviation is calculated from the static load distribution and the local stiffness and deviation ratios in the mesh.
